M2M 3G Modem from China manufacturer - Xiamen Four-Faith Communication Technology Co., Ltd.

Price:	1.0~999.0 USD
Payment Terms:	T/T,WU
Place of Origin:	Fujian, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: F2403

Production Capacity: 2,000 Piece/Pieces per Mont...

Delivery Date: 1 working day for sample/sm...

Means of Transport: Air

Packing: Standard Four-Faith carton ...

Brand Name: Four-faith

M2M Cellular 3G Modem:
1.TCP/IP protocol
2.Transparent data transmission.
3.Support TCP server and support multi TCP client connection

Detailed Product Description

Modem:
1.TCP/IP protocol
2.Transparent data transmission.
3.Support TCP server and support multi TCP client connection

Modem

1. General Information

F2403 WCDMA/HSDPA/HSUPA IP MODEM is a kind of cellular terminal device that provides data transfer function by public WCDMA/HSDPA/HSUPA network.

It adopts high-powered industrial 16/32 bits CPU and embedded real time operating system. It supports RS232 and RS485 (or RS422) port that can conveniently and

transparently connect one device to a cellular network, allowing you to connect to your existing serial devices with only basic configuration.

2. Product Feature

Design for Industrial Application

High-powered industrial cellular module
High-powered industrial 16/32 bits CPU
Support low-consumption mode, including sleep mode, scheduled online/offline mode, scheduled power-on/power-off mode(optional)
Housing: iron, providing IP30 protection.
Power range: DC 5~35V

Stability and Reliability

Support hardware and software WDT
Support auto recovery mechanism, including online detect, auto redial when offline to make it always online
RS232/RS485/RS422 port: 15KV ESD protection
SIM/UIM port: 15KV ESD protection
Power port: reverse-voltage and overvoltage protection
Antenna port: lightning protection(optional)

Standard and Convenience

Support standard RS232 and RS485(or RS422) port that can connect to serial devices directly
Support intellectual mode, enter into communication state automatically when powered
Provide management software for remote management
Support several work modes
Convenient configuration and maintenance interface

High-performance

Support TCP server and support multi TCP client connection(optional)
Support double data centers, one main and another backup
Support multi data centers and it can support 5 data centers at the same time
Support multi online trigger ways, including SMS, ring and data. Support link disconnection when timeout
Support dynamic domain name(DDNS) and IP access to data center
Design with standard TCP/IP protocol stack
Support APN/VPDN

3. Product Specification

Cellular Specification

Item	Content
Cellular Module	Industrial cellular module
Standard and Band	UMTS/WCDMA/HSDPA/HSUPA 850/1900/2100MHz, 850/900/1900/2100MHz(optional) GSM850/900/1800/1900MHz GPRS/EDGE CLASS 12
Bandwidth	HSUPA:5.76Mbps(Upload speed)/ HSDPA:7.2Mbps(Download speed)/UMTS:384Kbps (DL/UL)

Power supply

Item	Content
Standard Power	DC 12V/0.5A
Power range	DC 5~35V
Consumption	<250mA (12V)

Physical Characteristics

Item	Content
Housing	Iron, providing IP30 protection
Dimensions	91x58.5x22 mm
Weight	205g

Environmental Limits

Item	Content
Operating Temperature	-25~+65ºC (-13~+149°F)
Extended Operating Temperature	-30~+75ºC (-22~+167°F)
Storage Temperature	-40~+85ºC (-40~+185°F)
Operating Humidity	95% ( unfreezing)
